THA Series
Compared GNSS Receiver
THA-X601A
THA-X603A
THA-7603A
THA-7609A
THA-9603A
Satellites
GPS, GLONASS, BDS and GALILEO
GPS, GLONASS, BDS, GALILEO, QZSS and SBAS
GPS, GLONASS, BDS, GALILEO, QZSS, SBAS and IRNSS
Nominal Impedance
50Ω
50Ω
50Ω
50Ω
50Ω
Axial Ratio
≤3dB
Gain at Zenith(90°)
/
/
1205-1278MHz 4.2dBi(max)
1559-1615MHz 3.8dBi(max)
1166-1278MHz 2.6dBi
1559-1612MHz 2.8dBi
L-Band 1.5dBi
1166-1278MHz 2.4dBi
1559-1612MHz 2.5dBi
L-Band 1.0dBi
LNA Gain
33±2dB
23±2dB
33dB(typical)
33±2dB
Noise Figure
≤2dB
≤2dB
≤1.5dB
≤2dB
≤2dB
Output VSWR
≤2.0
Operation Voltage
+3.3VDC to +12VDC
+3.3VDC to +12VDC
+3.3VDC to +12VDC
+3.3VDC to +5VDC
+3.3VDC to +12VDC
Operation Current
55mA(maximum)
35mA(maximum)
55mA(maximum)
Operating Temperature
-40℃~+70℃
-40℃~+70℃
-40℃~+70℃
-40℃~+70℃
-40℃~+70℃
Connector
SMA male
Humidity
95% non-condensing
95% non-condensing
95% non-condensing
95% non-condensing
95% non-condensing
Protection
IP67
IP65
Dimension
Φ40mm*82.6mm
Φ27.5mm*59mm
Φ40mm*75.2mm
Φ43.6mm*40.8mm
Φ32.2mm*45.8mm
Weight
45g
25g
38g
30.5g
20g
